NPN | HW3G-B10N | HW3G-B20N |
PNP | HWBG-B10P | HW3G-B20 |
| Range setting distance | 20-100mm | 40-200mm |
| Detection distance | 20-100mm | 20-300mm |
Accept an assignment | Less than 2% of the movement distance (using white matte paper) |
repeatability | Along the detection axis: below 1mm, perpendicular to the detection axis; Less than 0.2mm (use white matte paper) |
Supply voltage | 12-24VDC±10%, pulsation below P-P10 |
Current consumption | Below 25mA |
exportation | <NPN output type> NPN open collector transistor Maximum inflow current: 100mA Applied voltage: below 30VDC (output between OV) Residual voltage: below 2V (when the inflow current is 100mA) Less than 1V (when the inflow current is 16mA) | <PNP Output type > PNP open collector transistor Maximum inflow current: 100mA Applied voltage: below 30VDC (output between OV) Residual voltage: below 2V (when the inflow current is 100mA) Less than 1V (when the inflow current is 16mA) |
Output action | ON during detection/ON during non-detection, equipped with two outputs |
Short circuit protection | assorting |
Reaction time | Less than 1ms |
Operating status light | Red LED(lights up when output is ON) |
Power indicator light | Green LED(powered on) |
Range-setting regulator | Mechanic S ring regulator |
Detection mode | BGS function |
Automatic anti-interference function | assorting |
Protective construction | IP67 |
Operating ambient temperature | 25℃ to +55℃(pay attention to no condensation, icing), storage: -30℃ to +70℃ |
Ambient humidity | 35~80%RH, storage: 35~80RH |
Use ambient lighting | Incandescent lamp: illuminated surface below 3000lux |
Withstand voltage | AC1000V 1 min All power connections between terminals and housing |
Insulation resistance | All power connection terminals and housing, more than 20MΩ, based on DC250V high resistance meter |
Vibration resistance | Frequency 10-500Hz Double amplitude 3mm(MAX,50G)X,Y and Z directions for 2 hours each |
Impact resistance | Acceleration 500m/s²(about 50G)X,Y and Z directions for 2 hours each |
Beam element | Red LED(peak wavelength: 650mm, modulated) |
| Photoelectric diameter | Approx. φ2mm(at a distance of 50mm) | About φ20mm(when the distance is 300mm) |
| material | Shell PC |
cable | φ3.8 cable, 4 cores, length 2m |
