End Style Union

◆Property: Thickened zinc alloy or chromium plated;nice looking,compact structure and high strength.
Flexible conduit Ferrule design make conduit connection tightly,easy assembly,and strong pull resistance.

Availability:



Inquire Add to Basket

Brand:
YUANKY
Intercontinental Product:
America

Product Description

◆Product material:Location A.C and Fare made of high-quelitv thickened zjnc alloy,B.E made of Chemigums and Dis made of iron sheet.

◆Specification fo thread:G,NPT

◆Color:Metallic color (silver white)

◆Working temperature:-40℃~+100℃,instantaneously can be+120℃

◆Protection:IP65

◆Property: Thickened zinc alloy or chromium plated;nice looking,compact structure and high strength.

Flexible conduit Ferrule design make conduit connection tightly,easy assembly,and strong pull resistance.

Water resistant,dust resistant,inactive with slts,acid and alkali resistance,alcohols,oils and greases

as well as general solvent.

Besides the following specifications,the size and thread standard can be varied at your discretion as pe requirements.

规格参数

产品型号 ltem No.	公制 M	英制 G	螺纹外径 Thead O.D(mm)D1	螺纹长度 Thead Length(mm)L1	接合长度 Connector Length(mm)L1+L2	包装单位(个/包) Packaging unit
-6	中6	G1/4°	13.2	8	16	00
HW-DPJ-8	中8	G3/8°	16.5	8	16	100
HW-DPJ-10	中10	G3/8°	16.5	8	17	100
HW-DPJ-13	中13	G3/8°	16.5	8	18	100
HW-DPJ-16	φ16	G1/2'	21.3	11	23	100
HW-DPJ-20	中20	G3/4'	26.6	14	22	50
HW-DPJ-25	φ25	G1"	33.4	5	配	50
HW-DP-32	中32	G1-1/4°	42.1	15	品	25
HW-DPJ-38	φ38	G1-1/2	47.8	16	32	25
HW-DPJ-51	中51	G2	59.6	18	34	10
HW-DPJ-64	中64	G2-1/2	75.1	22	38	10
HW-DPJ-75	φ75	G3"	87.8	22	46	5
HW-DPJ-100	φ10	G4“	113	24	50	5
HW-DPJ-125	φ125	G5°				5
HW-DPJ-150	中150	G6				2
